【适用范围】

This instrument is suitable for testing the color fastness of all textiles (excluding loose fibers) when exposed to atmospheric nitrogen oxides generated by the combustion of chemical butane gas or city gas.

【相关标准】

AATCC23, ISO105-G02,GB/T11039.

[Scope of Application]

This instrument is suitable for testing the color fastness of all textiles (excluding loose fibers) when exposed to atmospheric nitrogen oxides generated by the combustion of chemical butane gas or city gas.

[Compliant Standards]

AATCC 23, ISO 105-G02, GB/T 11039.

[Technical Parameters]

1．Rotating Frame Speed: ≈2 R/MIN (Revolutions Per Minute)

2．Test Chamber: SUS material

3．Sample Specification: 100mm×40mm

4．Test Temperature: ≤60℃

5．Control Method: PLC control

6．Combustion Gas: Chemically pure butane gas or city manufactured gas

7．Dimensions: 62×70×82mm

8．Weight: 75KG

9．Power Supply: AC 220V 50HZ 3A

[Test Principle]

Textile samples and control standards are placed in the gas fumes simultaneously. The test ends when the color of the control standard changes to a color equivalent to the fading standard. A gray scale is used to evaluate the color change of the samples.If no color change of the samples is observed after one test cycle, the test cycles can be continued for a specified number of times or the number of times required to cause color change of the samples.

[Standard Consumables]

Control Sample Card

Reference Sample Card

[Optional Accessories]

Gray Sample Card
