织物透气度测试仪,测量织物的 允许空气通过的能力。 透气度值 对于依赖纺织品透气性的应用来说,这一点至关重要。例如,在户外服装中, 高透气性 可能需要舒适的空气渗透率,而在防风或防水纺织品中,可能需要较低的空气渗透率值。
研硕研发了多种型号的纺织品透气度测试仪,每款都有其独特的功能。您总能找到适合您实验室的测试仪。 透气性值 根据不同的透气标准和透气测试。
[Scope of Application]
Used to test the air permeability of various materials, including fabrics, non-woven fabrics, industrial filter cloths, paper, and various filter materials.
[Compliant Standards]
GB/T 5453, ASTM D737, ASTM D3574, EN ISO 7231, EN ISO 9237, BS 5636, DIN 53887, JIS L1096-A, AFNOR G07-111, EDANA 140.1/2, TAPPI T251, etc.
[Instrument Features]
1.Fast testing speed, with a regular test taking approximately 10-15 seconds.
2.Equipped with an industrial color touch screen for operation, supporting both Chinese and English menu display.
3.Allows arbitrary setting of parameters and units according to different national standards; test results require no conversion and can be directly printed out.
4.Fully complies with standards of various countries, and its stability, repeatability, and reliability completely reach the advanced international level.
5.Adopts imported pressure sensors from international brands to ensure the accuracy of test data.
6.Equipped with lockable and silent universal casters for easy movement.
7.Equipped with a retractable workbench, which meets testing needs and saves space.
[Technical Parameters]
1.Pressure Range: 0-300 pa; 0-4000 pa (optional)
2.Measurement Units: mm/s; cfm; cm³/cm²/s; L/m²/s; L/dm²/min; m³/m²/min; m³/m²/h; dm³/(S·25cm²)
3.Testing Range: 0.2-12826 mm/s
4.Display Resolution: 0.01
5.Testing Accuracy: ≤±2%
6.Sample Thickness: ≤12 mm
7.Instrument Calibration: Calibration with standard orifice plate
8.Power Supply: AC 220V ±10%
9.Power: 1100 W
10.Overall Dimensions: 450×710×1000 mm
11.Net Weight: 115 kg
[Scope of Application]
Used to test the air permeability of various materials, including fabrics, non-woven fabrics, industrial filter cloths, paper, and various filter materials.
[Compliant Standards]
GB/T 5453, ASTM D737, ASTM D3574, EN ISO 7231, EN ISO 9237, BS 5636, DIN 53887, JIS L1096-A, AFNOR G07-111, EDANA 140.1/2, TAPPI T251, etc.
[Instrument Features]
1.Fast testing speed, with a regular test taking approximately 20-30 seconds.
2.Equipped with a color touch screen for operation, supporting both Chinese and English menu display.
3.Allows arbitrary setting of parameters and units according to different national standards; test results require no conversion and can be directly printed out.
4.Fully complies with standards of various countries, and its stability, repeatability, and reliability reach the advanced international level.
5.Adopts imported pressure sensors from international brands to ensure the accuracy of test data.
6.Equipped with lockable and silent universal casters for easy movement.
7.Equipped with a retractable workbench, which meets testing needs and saves space.
[Technical Specifications]
1.Pressure Range: 0-300 pa
2.Measurement Units: mm/s; cfm; cm³/cm²/s; L/m²/s; L/dm²/min; m³/m²/min; m³/m²/h; dm³/(S·25cm²)
3.Testing Range: 0.2-12826 mm/s
4.Display Resolution: 0.1
5.Testing Accuracy: ≤±2%

YG461E-Ⅱ Industrial Filter Cloth Air Permeability Tester

YG461E-ⅠType Non-woven Fabric Air Permeability Tester

YG461H Fully Automatic Air Permeability Tester

YG461E Fabric Air Permeability Tester

YG461E-III Digital Air Permeability Tester
