【适用范围】

It is suitable for general fibrous sheet products: apparel fabrics, home textile fabrics, nonwovens, yarns, automotive interiors, leather, paper, etc.

【相关标准】

暂无

【Instrument Features】

1．Vividly simulates human hands.

2．Quantifies indicators for more scientific results.

3．Simple operation with single-machine and single-test for multiple indicators.

4．Combines mechanical models with physical testing.

5．High cost performance, equipped with high-precision components, ensuring high control accuracy and stable performance.

【Technical Parameters】

1．Sample Size: 50×500mm

2．Maximum Thickness: 4mm

3．Test Range: 0-80mm

4．Power Supply: AC220V, 50Hz

5．Overall Dimensions: 500mm×480mm×780mm (L×W×H)

6．Weight: 100kg

【Testing Principle】

It simulates the subjective feeling process of human hands on fabrics. The indenters used are cylindrical, vividly simulating human fingers with fine textures to mimic fingerprints. The indenter layout (one upper and two lower) simulates the human touching process. The system quantifies corresponding indicators through physical tests such as compression, bending, friction and stretching of materials, obtaining curved surface compression thickness, softness (SF), stiffness (ST), slipperiness (SM) and tightness (LT), and then evaluates the comprehensive style of fabrics.

1．Thickness indicator: The thickness of the fabric under curved surface compression.

2．Stage Ⅰ: Curved surface compression obtains compression modulus, compression deformation, etc., expressed as softness (SF).

3．Stage Ⅱ: Bending test obtains maximum bending value, bending modulus, bending work, etc., expressed as stiffness (ST).

4．Stage Ⅲ: Friction test obtains average friction force, friction coefficient, friction work, etc., expressed as slipperiness (SM).

5．Stage Ⅳ: Tensile test obtains tensile modulus, tensile work, etc., expressed as tightness (LT). Comprehensive evaluation of test results: Comprehensive style (CH) = ASF + BST + CSM + DLT. Each indicator (SF, ST, SM, LT) is classified into five grades (Grade 1 to Grade 5). The comprehensive style is the weighted sum of softness, stiffness, slipperiness and tightness. Coefficients A, B, C and D are comprehensively determined according to the material's application, type, texture, etc.
